卓越效能展現
支援 Intel® Celeron, Alder Lake P, U 系列 i3 與 i5 處理器。
單一面板,無限可能
PPC-238 是一款高效且具成本效益的面板電腦解決方案,專為零售與餐飲旅宿應用而設計。
PPC 系列旨在透過標準顯示尺寸滿足各種專案需求:
21.5″ ( 16:9 ), 23.8″ ( 16:9 ) and 32″ ( 16:9 )
除了這些選項外,我們也根據需求提供客製化顯示尺寸,確保您的獨特規格與專案需求得到全力支援。
滿足您對複雜效能的需求。搭載 Core™ i7, U 系列處理器的 Power PC-U 系列,能提供強大的效能與可靠度,以處理高負載的應用程式。
它們支援多工處理、快速數據處理以及靈活的連線功能,是工業與商業應用的穩固選擇。
具備靈敏的 10 點投射式電容 ( PCAP ) 多點觸控面板,提供準確的使用者體驗。
PPC-238 提供可靠的無線連線選項,配備外部天線,確保商業用途中的穩定訊號效能。
採用 mini PCIe 形式,可獨立整合 Wi-Fi 與藍牙模組,提供靈活且具擴展性的連線選擇。



在空間受限的情況下,最大限度地減少技術設備佔用空間,並最大限度地擴大工作區域。
我們多樣化的安裝方案可為任何企業打造現代化美觀的工作環境。
此操作盤 ( Bump Bar ) 與我們最新的 PPC 系列無縫連結,專為廚房顯示系統 ( KDS ) 打造。
具備 IPX5 防護等級的操作盤專為耐用性設計,可承受嚴苛環境並具備防潑水功能,是廚房管理與生產環境中可靠的組成組件。
| System Information | PE24 PE26 System Memory Intel® AMT TPM |
|---|---|
| Display & Touch | – 21.5″ Full HD Display, resolution 1920×1080 – 250cd/m², LED backlight – 10-point PCAP multi-touch screen |
| Storage | – PE24: 1 x M.2 PCIe SSD – PE26: 1 x M.2 PCIe SSD or 2 x 2.5″ SSD for RAID 0/1 (Project based) |
| Expansion | – 1 x M.2 E Key (for WiFi/BT project based) |
| Connectivity | – 3 x USB 2.0, 3 x USB 3.1 |
| Audio | – 2 x 2W speaker |
| Power Requirement | – Input: 100 – 240Vac/ 50 – 60Hz – Output: DC+19V, 90W AC to DC Adapter |
| Mechanical & Construction | – Front panel IP65 – System fan: Fanless operation – Weight (NW/GW): 7 Kgs / 9 Kgs – Dimension (WxHxD): 573.36 x 342.59 x 56.89 mm – Mounting: Wall / Pole / VESA 100×100 – Construction: Aluminum frame with sheet metal chassis |
| Environmental | – Operating temperature: 0°C ~ 40°C, 10% ~ 90% Relative Humidity, Non-condensing – Storage Temperature: -20°C ~ 60°C, 10% ~ 90% Relative Humidity, Non-condensing |
| Certification | – CE/FCC/LVD |
| OS Support | – Windows 10/11 (64 bit), Linux (Ubuntu 22.04) |
Note: The need for point of sale terminal that perform at its best is crucial for productivity, usability, accuracy and delivering the best user experience.
