M227 ( 15.6" )
極簡設計，極大靈活性
產品特色
- 15.6 吋 16:9 全平面 P-cap 觸控螢幕顯示器。
- 專為嚴苛環境設計的全平面面板。
- 防潑水與防塵保護。
- 支援 VGA + DP 連線。
- 堅固的雙鉸鏈金屬底座。
- 可拆卸式底座 / 支援 VESA 壁掛安裝。
- 適用於各種餐飲旅宿與零售應用。
- 具備 OSD 顯示功能。
Product Highlights
15″ True-Flat
IP54
Proof
Supports
2nd Display
VESA
Compliance
75*75
/ P-Cap Touch
or
/ Non-Touch
觸控螢幕顯示器
具備流暢互動體驗的 15.6 吋 16:9 螢幕
配備高強度玻璃的顯示器提供廣視角與更精準的色彩呈現。
15.6 吋
16:9
1920 x 1080
解析度
10 Points
投射式電容觸控
350
cd/m²
專為零售與餐飲旅宿設計的 15.6 吋 16:9 IP54 全平面顯示器
Poindus M227 是一款現代化顯示器，前邊框具備防潑水與防塵功能。
非常適合零售環境中的客戶資訊顯示、查價機與互動式看板。
USB-C、Display Port 與 VGA 連線能力
支援 USB-C、DisplayPort 與 VGA 連線，符合現代相容性與靈活性需求。
IP54 防護等級
- 前邊框防護等級。
- 防潑水與防塵。
SoftPOS Payment Support
- 10.1” 2nd display for interactive payment.
- Supports Windows-compatible SoftPOS with NFC payment.
- Simplifies checkout and enhances experience.
Suitable for customer information, CCTV monitoring, shelf‑end marketing, and general signage.
應用場景
Optional Accessories for More
Efficient Operations
Easy Installation
VESA compliance
75*75
schematic
產品圖片
產品規格
| Description | 15.6″ True-flat PCAP Touch Monitor |
|---|---|
| Display size | 15.6″ (16:9) |
| True-Flat | YES (IP54 Front Panel) |
| Interface | USB-C, DisplayPort & VGA Video + Audio + USB (Touch) |
| Optimal Resolution | 1920 x 1080 |
| Brightness (Panel)3 | 350 cd/m² |
| Contrast Ratio | 1000:1 |
| Response Time (ms) | 30 ms |
| Power supply | – DC-12V, 20W adaptor or Tpye-C (PD) |
| OS Support | Windows 10 / 11 |
| Touch type | 10-point Projected Capacitive Multi-touch |
| Input Terminals | For Video Signal For Power For Touch Signal For Audio |
| Physical Dimension | Dimensions (W x H x D) mm Weight (N.W./G.W.) (Kg) |
| Environment | Operating temperature: 0°C ~ 40°C, 10% ~ 90% Relative Humidity, Non-condensing Storage Temperature: -10°C ~ 50°C, 10% ~ 90% Relative Humidity, Non-condensing |
| Certifications EMI/Safety | CE, FCC |
| Options | Wall Mount Kit Base Speakers Color |
Note: The need for point of sale terminal that perform at its best is crucial for productivity, usability, accuracy and delivering the best user experience.
