Panel PC
Panel PC designed to thrive in harsh environments and fit into any scenario.
VariPPC 250/270
Series
Take Your Store Experience to the Next Level
- Intel 6th to 12th Generation Celeron i3, i5 high-end processors in a fanless structure.
- True flat 15” 4:3 / 17″ 5:4 LCD (LED backlight), 400 nits with IP66 protection.
- All in One POS configuration available.
- High speed Type C interface for customizable IO box to meet project specification.
- 1 x 24V, 2 x 12V Powered USB for retail peripherals (IO box) (Option).
- Quick SWAP IO box for easy maintenance.
- Peripheral compatibility across the whole VariPOS 2 Series: MSR, iButton, Fingerprint, RFID.
- TSE Adapter for VariPOS (KassenSichV) Compliant
All in One Mountable Aesthetic Panel PC
Designed for Diverse Applications
VariPPC 250i durability and flexibility meets the demand with Pole- or Wall mountable options and frees up space for application, especially in hospitality & retail scenario. The aesthetic appearance & slim panel configures All in One POS function can build your business to a higher level elegantly.
Deliver the Power to Perform
Full Range Intel Processors
Supports Microsoft Windows platform from POS Ready 7 to Windows 10 (32/64bit) ensures compatibility with your preferred Windows software solution.
FANLESS
Fan-less architecture has the benefit of silent running and prolongs the life of the terminal, ensuring a great return on investment.
Intel TPM
Intel Core processors protect IoT systems and data through hardware- and software-based security hardening, keeping connected devices secure.
Powered USB Connections
The I/O provides everything you would expect from a high performance POS terminal including Powered USB for your retail peripherals.
IP66 Spill Proof
Combined with Front Panel IP66 (Ingress Protection) dust and waterproof protection, is perfectly suited for the rigors of hospitality and retail environments.
High Speed USB Type C Connector
Redefining Service
The flexibility of VariPPC 250i transforms any retail spaces into
versatile pay points and strategic touch points with the customizable I/O box
which connects all your devices through a single high speed USB Type C connector maintaining high I/O transfer rates.
The independently mountable I/O box for Panel PC configuration ensures a clutter-free point of sale station with advanced cable management; overcoming project limitations with advanced customization options.
Poindus Retail-hardened solutions help retailers maintain high uptime ensuring transactions are completed and minimize the need for technical after-service.
Retail Hardened Pole Mounted POS designed for the demands of the retail & hospitality world
An Ideal Retail-Ready Solution
with Advanced I/O Customization
Independently mountable I/O box for Panel PC configuration provides
clutter-free point of sale stations with advanced cable management.
The extendable I/O box supports for all the retail peripheral products to
establish a complete retail environment and level up your sales force.
Overcome project limitations whatever the deployment, Check-out,
interactive signage or self-service kiosk.
VariPPC 250 (PE17) with I/O Box (PE18)
Efficient Service Benefit
with Quick Swap & Maintenance
Simplified Installation and Serviceability has been designed in to the VariPPC 250i to provide quick and easy service for routine maintenance schedules, significantly reducing engineer onsite visit time.
The quick service design reduces downtime and is easy to clean and maintain for the user; reducing service resources and lowering the total cost of ownership (TCO).
Specification
| VariPPC 250i/270i (PE17 MB + PE18 VariIO I/O Box) VariPPC 250A/270A (PE24) (PE26) |
|||
| Main Board | |||
| VariPPC 250i/270i (PE17) | VariPPC 250A/270A (PE24) | VariPPC 250A/270A (PE26) | |
| Processor | Intel® Core™ i5-7300U Intel® Core™ i3-6100U Intel® Celeron® 3955U |
Intel® Celeron® J6412 | Intel® Alder Lake-P Platform i5-1235U i3-1215U |
| Chipset | CPU Integrated | ||
| System Memory | 1 x SO-DIMM DDR4 slot, 4GB RAM as standard. Max. memory support up to 16GB. Easy acess with secured cover for easy maintainence. |
1 x 8GB DDR5 SO-DIMM memory. Max. support up to 32GB. |
|
| TPM | Intel F/W | ||
| Intel AMT | i5 CPU Only | ||
| Display & Touch | |||
| LCD Size | 15″ 4:3 TFT LCD (LED backlight) | ||
| 17″ 5:4 TFT LCD (LED backlight) | |||
| Brightness | 400nits | ||
| Resolution | 15″ 1024 x 768 (4:3) | ||
| 17″ 1280 x 1024 (5:4) | |||
| Touch | True Flat Projected Capacitive Technology 10 point Multi-touch |
||
| Storage | |||
| HDD/SSD | 1 x SATA III (2.5”) | 1 x SATA III (2.5”) or M.2 Storage (Option) | |
| Panel I/O | |||
| LAN Port | 1 x Gigabit Ethernet by RJ-45 | ||
| USB Port | 2 x USB 3.0 | 3 x USB 2.0, 3 x USB 3.1 | |
| COM Port | N/A | 2 x RJ48 (Support DC+0/5/12v by BIOS setting, (Default Setting is 0v) |
|
| Cash Drawer | N/A | 1 x RJ11 (Support DC+12v or +24v (default)) port supports 2 cash drawers |
|
| Speaker | HD Audio, 2W Speaker x 2 | ||
| Power Switch | 1 x power on/off button | ||
| DC Input | 1 x Mini Din 4P (DC+19v only) | ||
| VariIO I/O Box & Expansion (Optional) | |||
| Cash Drawer | 1 x RJ-11 (Support DC +12V or +24V (default)) port supports 2 cash drawers | ||
| LAN port | 1 x Gigabit Ethernet by RJ-45 | ||
| USB port | 2 x USB 3.0 | ||
| 4 x USB 2.0 | |||
| Powered USB Port *PUSB version Only |
2 x DC+12v Powered USB | ||
| 1 x DC+24v Powered USB | |||
| COM port | 4 x RS-232 (jumper setting, support DC+0/5/12v, default setting is 0v) | ||
| Type C | N/A | 1 x Type C | |
| OS Support | |||
| Win 10 ( 64bit ) / Win 7 (32bit/64bit) | Windows 10 (64bit) | Windows 11 (64bit) (Option) | Linux | ||
| Power Adapter | |||
| External Adapter | Voltage:+19VDC, Std. 90 watt *PUSB will use 180 watt adapter | Voltage:+19VDC, Std. 65 watt *PUSB will use 180 watt adapter |
Voltage:+19VDC, Std. 90 watt *PUSB will use 180 watt adapter |
| Compliance | |||
| Certifications | CE, FCC, LVD, RoHS | ||
| Protection | IP 66 on front panel | ||
| Material | |||
| Main Unit: Die-Cast Aluminum | |||
| Color | |||
| Main Unit: Space Gray / Black | |||
| Dimension( Wx H x D mm) | |||
| 15″ – 365.893 x 281.89 x 43.23 (PPC) 17″ – 396.93 x 329.47 x 42.75 (PPC) |
|||
| Environmental Condition | |||
| Operating | 0°C ~ 40°C, 10% ~ 90% RH, non-condensing | ||
| Storage | -20°C ~ 60°C, 10% ~ 90% RH, non-condensing | ||
| Optional Accessories (More Information) | |||
| MSR | ISO 3-Tracks Slim MSR USB Type | ||
| ibutton | Dallas Key Reader,USB Type | ||
| RFID | 13.56Mhz USB Type | ||
| Fingerprint | DigitalPersona U.are.U 4500 Module, USB Type | ||
| Scanner | 2D scanner, USB Type | ||
| Packaging | |||
| Carton | L 460 x W 300 x H 510 mm (15″) / L 495 x W 315 x H 550 mm (17″) | ||
