All In One
PT Series POS Systems, respond to market demand.
PT56B
Streamlined Style.
Unmatched Functionality.
Unmatched Functionality.
- Supports CPUs from Celeron J6412 to Intel 12th Gen. Core i3/i5
- 4.8mm slimmest bezel in the present market.
- Easy service cover for Memory Module & M.2 SSD.
- Quick release of dual IO covers for easy access & peripherals installation.
- Optional IO module for Power USB.
The Complete POS Solution
Delivering Stability & Performance
The state-of-the art PT56B presents a stylish and modern POS system with cutting edge of mechanical design and hidden cable management delivering a space saving solution. The PT56B guarantees stability and high performance to enhance customer experience. Seamless integration of various peripherals such as MSR, Second Display and Customer Display to meet project requirements.
With a modern slim bezel design widescreen display that seamlessly merges style with practicality. The sleek and contemporary widescreen format allows System Integrators to leverage this intuitive widescreen platform to design menu layouts that are both visually engaging and user-friendly, catering to diverse needs across retail, hospitality, and industrial applications.
Deliver the Power to Perform
Intel
Celeron J6412 to
12th Gen. Core i3/i5
Reliable Intel Processing
IP54 Ingress
Spill Proof
Front Panel IP54 (Ingress Protection) dust and waterproof protection
Robust
Stand
Stand for the perfect tilt adjustment
Multiple Mount
Options
Wall, Pole & Stand Mount Configurations
Power your Retail Devices
Simplify Integration with P-USB
The PT56B supports P-USB Powered equipment eliminating the need for external power supply adapters to power USB peripherals at your retail locations. It makes Point of Sale peripherals more dependable with a single connecting cable providing data and power. It additionally helps drastically with cable management and keeping a clean workspace and also simplifies engineer visits for scheduled maintenance.
You can connect powered USB devices such as receipt printers, barcode scanners, and other capture devices to the PT56B POS system, without having to power these devices individually with additional power adapters.
Specification
| PT56 (PE24) PT56 (PE26) |
|||
| Main Board | |||
| PT56 (PE24) | PT56 (PE26) | ||
| Processor | Intel® Celeron® J6412 | Intel® Alder Lake-P Platform i5-1235U i3-1215U |
|
| Chipset | CPU Integrated | ||
| System Memory | 1 x SO-DIMM DDR4 slot, 4GB RAM as standard. Max. memory support up to 16GB. | 1 x 8GB DDR5 SO-DIMM memory (Max.support up to 32GB) |
|
| TPM | Intel F/W | ||
| Intel AMT | N/A | i5 CPU Only | |
| Display & Touch | |||
| LCD Size | 15.6″ 16:9 TFT LCD(LED backlight) | ||
| Brightness | 350nits | ||
| Resolution | 1920 x 1080 (16:9) | ||
| Touch | True Flat Projected Capacitive Technology | ||
| Storage | |||
| HDD/SSD | 1 x M.2 PCIE Gen 3 | ||
| Panel I/O | |||
| LAN Port | 1 x Gigabit Ethernet by RJ-45 | ||
| USB Port | 4 x USB 2.0, 3 x USB 3.1 | ||
| COM Port | 2 x COM (COM 1/2: RG48 Support DC to 5/12v by BIOS Setting) Default Setting is 0v |
||
| Cash Drawer | 1 x RJ11 (Support DC+12v or +24v (default)) port supports 2 cash drawers | ||
| Type C | 1 x Type C | ||
| Speaker | HD Audio, 2W Speaker x 2 | ||
| Power Switch | 1 x power on/off button | ||
| DC Input | 1 x Mini Din 4P (DC+19v only) | ||
| OS Support | |||
| Windows 10 (64bit) | Windows 11 (64bit) (Option) | Linux | |||
| Power Adapter (External Adapter) | |||
| Voltage:+19VDC, Std. 65 watt | Voltage:+19VDC, Std. 90 watt | ||
| Compliance | |||
| Certifications | CE, FCC, LVD, RoHS | ||
| Material | Main Unit: Plastic | ||
| Color | Main Unit: Black | ||
| Dimension ( W x H x D mm ) |
359.8 x 261.2 x 178 mm | ||
| Environmental Conditions |
Operating: 0°C ~ 40°C, 10% ~ 90% RH, non-condensing Storage: -20°C ~ 60°C, 10% ~ 90% RH, non-condensing |
||
| Optional Accessories | |||
| MSR | ISO 3-Tracks Slim MSR USB Type | ||
| ibutton | ibutton Dallas Key Reader,USB Type | ||
| RFID | 13.56Mhz USB Type | ||
| Fingerprint | DigitalPersona U.are.U 4500 Module, USB Type | ||
| Scanner | 2D scanner, USB Type | ||
| 2nd Display | 10.1 ” Resolution 1280 x 800 (16:10 wide screen) USB Type, Non Touch | ||
| LCM | 2×20 LCM, USB Type | ||
| Packaging Carton | L460 x 300 x H510 mm | ||
| e-Brochure and Datasheet↓ | |||
