Kiosk
Self Service Solutions from Poindus.
VariKIOSK 217
17.3″ Desktop Self Service Kiosk
- Fully integrated AIO desktop self-service kiosk.
- Support Intel® 12th Generation Core i3 & i5 CPU.
- Intel® TPM protect system & data with software-based security hardening.
- True flat 17.3″ 9:16 LCD, 300 nits brightness with front bezel IP54 dust & spill water resistant.
- Rotatable Display (Horizontal or Vertical) (optional)
- Turntable Base to allow cahier or customer facing interactions (Optional)
- Swivelable Payment Terminal Brackets simple payment integration (Optional)
- Design flexibility of front bay to accommodate various printers and scanners
- Multiple Rear Display Options (optional)
- Integrated AI Camera (optional)
- RAID 0/1 function with dual SSD/HDD support (optional).
- Durable die-cast aluminum chassis; built to last.
- Redefines serviceability from design with easy access & quick swap modular design for
- SSD/HDD & MB box.
Retail Ready Kiosk
Full HD Display Optimized
for Modern Retail
for Modern Retail
VariKIOSK 217 can be configured to meet custom project demands, offering vertical or horizontal displays, and suppots a variable selection of printer and scanner devices in the front bay. It also supports a selection of rear display sizes and an integrated camera module for AI recognition. VariKIOSK also has mounting options for third party payment terminals making it the perfect desktop kiosk for retail and hospitality environments.
Our kiosk solutions are designed for the rigors of retail and hospitality scenarios, serving as compact, efficient solutions for enhancing customer experience and streamlining store operations. These interactive devices can facilitate self-service checkouts, provide product information, and assist in wayfinding within the store. With their ability to operate independently, desktop kiosks can effectively reduce wait times and free up staff to focus on more complex customer service tasks.
A versatile tool for retailers looking to improve service quality and operational efficiency
Deliver the Power to Perform
True flat 17.3″
Display
16:9 LCD
300 nits brightness
Intel® 12th Generation
Core i3/i5 CPU.
Reliable
Intel Processing
IP54 Ingress
Spill Proof
Front Panel IP54 (Ingress Protection) dust and waterproof protection
Redefined
Serviceability
Quick swap modular design
for SSD/HDD & MB box
Multifunctional Kiosk
POS Mode & Self Checkout Mode
In addition to its flexible configuration options, the VariKIOSK 217R offers true multifunctionality by supporting both POS and Self-Checkout kiosk use in a single compact unit. Designed with system integrators in mind, this model features an optional turntable base that allows the entire unit to rotate, facing the operator during assisted transactions or turning toward the customer for self-service. The main display can be rotated between horizontal (landscape) orientation for POS mode and vertical (portrait) orientation for kiosk mode, adapting easily to different usage scenarios. The payment terminal bracket is also rotatable, enabling the device to be positioned correctly for either operator or customer interaction.
In POS mode, the screen is set to horizontal with the rear customer display and payment terminal facing the customer. For kiosk mode, the screen is rotated vertically, the payment device is swiveled to face the front, and the unit is turned toward the customer. This dual-function capability reduces hardware investment, simplifies deployment, and provides a smart, space-saving solution for retail and hospitality environments.
An all-in-one solution for streamlined deployment and flexible customer interaction.
Desktop Kiosk
VariKIOSK has a compact footprint for space restricted environments
Vertical Only Orientation
VariKIOSK 217
Horizontal or Vertical Orientation
VariKIOSK 217R
Compact kiosks are a smart solution for businesses operating in areas where space is at a premium. The small footprint allows for efficient use of available counter space, which is particularly beneficial in retail and hospitality scenarios. VariKIOSKs can offer a wide range of services, from information access to transaction processing, without the need for extensive physical infrastructure. By integrating technology and design, compact kiosks can enhance customer experience while also contributing to a streamlined and modern aesthetic within the establishment.
Specification
| VariKIOSK 217 (PE26) | |||
| Main Board | |||
| VariKIOSK 217 (PE26) | |||
| Processor | Intel® Alder Lake-P Platform i5-1235U up to 4.4 GHz i3-1215U up to 4.4 GHz |
||
| Chipset | Iris® Xe Graphics eligible | ||
| System Memory | 1 x SO-DIMM DDR5 slot, 8GB RAM as standard. Max. memory support up to 32GB | ||
| TPM | Intel® TPM 2.0 | ||
| Display & Touch | |||
| LCD Size | 17.3″ 16:9 TFT LCD(LED backlight) | ||
| Brightness | 300nits | ||
| Resolution | 1920 x 1080, Full HD | ||
| Touch | True Flat Projected Capacitive Technology | ||
| Orientation | Rotatable Screen (Optional) | ||
| Storage | |||
| HDD/SSD | 2.5” 256G (Default) as standard | ||
| RAID | *Project Based | ||
| Panel I/O | |||
| LAN Port | 1 x Gigabit Ethernet by RJ-45 | ||
| USB Port | 3 x USB 2.0, 3 x USB 3.1 | ||
| COM Port | 3x COM (COM1/2: RJ48 support DC+0/5/12v by BIOS setting, default setting is 0v. COM3: DB-9) |
||
| Cash Drawer | 1 x RJ-11 (Support DC +12V or +24V (default)) port supports 2 cash drawers | ||
| VGA | 1 x DB-15 VGA port Power enable by BIOS setting (default disable) | ||
| BUS Expansion | 1 x M.2 M Key for SSD 1 x M.2 E Key |
||
| Type C | 1 x Type C (PD + DP) | ||
| Powered USB port | 2 x DC+12v and 1 x DC+24v (Project Based) | ||
| Speaker | HD Audio, 2W Speaker x 2 | ||
| Power Switch | 1 x power on / off switch button | ||
| DC Input | 1 x Mini Din 4P (DC 19V only) | ||
| OS Support | |||
| Win 11 IoT GAC | |||
| Power Adapter (External Adapter) | |||
| DC+19V, 90watt | |||
| Peripherals | |||
| Handheld scanner – Newland NLS-HR3280 2D Scanner – Datalogic Magellan1500i Omnidirectional scanner – Datalogic Magellan M3450 Printer – Epson TM-M30 III 10.1“ 16:10 @ 1280 x 800 2nd screen PinPad Bracket for Verifone VX820 Turntable Base (Optional) |
|||
| Compliance | |||
| Certifications | CE, FCC, LVD, RoHS | ||
| Ingress Protection | IP54 Front Panel | ||
| Material | Main Unit: Die-Cast Aluminum ; I/O Cover:Plastic | ||
| Color | Main Unit: White | ||
| Dimension ( W x H x D mm ) |
Vertical mode Main Unit: 270 x 608.7 x 234.6 mm Main Unit + Peripherals: 377.6 x 608.7 x 234.6 mm |
||
| Horizontal mode Main Unit: 437 x 533.7 x 216.9 mm Main Unit + Peripherals: 489.6 x 533.7 x 237.1 mm |
|||
| Weight | 12kg | ||
| Environmental |
Operating: 0ºC ~ 40ºC, 10% ~ 90% RH, non-condensing Storage: -20ºC ~ 60ºC, 10% ~ 90% RH, non-condensing |
||
