Display
Display solutions that allow touchpoint deployment in multiple situations.
True-Flat-PCAP-Touchscreen (15 Zoll)
Modelnummer: M457TB/M457PB
- Resistiver PCAP-Multitouch-Bildschirm
- Einfache Wartung
- Elegantes und modernes Design
- IP-Schutzklasse: IP54
- MSR-Leser, Fluoreszenzanzeige und 2. Display optional
- VESA-Halterung für flexible Montage
Specification
| M457 | |
| Description | |
| 15″ VGA/DVI Resistive (4:3) |
|
| 15″ VGA/DVI PCAP (4:3) | |
| Display | |
| Display Size | 15″ |
| True-Flat | YES ( IP54 on front panel ) |
| Interface | VGA + DVI |
| Resolution | 1024 x 768 |
| Viewing Angle | 70/70/80/80 degree (U/D/L/R) |
| Brightness (nits) | 350 |
| Contrast Ratio | 800: 1 |
| Response Time (ms) | 8 |
| Power Supply | DC 12V ± 10% |
| OS Support | Windows 10, 8.1, 8, 7 |
| Touch Type | |
| Touch Type | M457PB – Projected Capacitive (USB) |
| M457TB – Resistive (USB or RS232) | |
| Input Terminals | |
| Video Signal | D-Sub 15-pin, DVI-D |
| Power | DC Jack |
| Touch Signal | USB Type B |
| VFD | RJ45 (10 Pin) |
| Peripherals | USB Type A *2 |
| Audio | Option |
| Physical Dimension | |
| Dimensions (W x H x D) mm |
365.2 x 333.6 x 200 |
| Weight (N. W.) (Kg) | 4.6 |
| Environment | |
| Operating Condition | 0ºC~40ºC |
| Storage Condition | -10ºC~50ºC |
| Power Consumption | Max. 20W Operation / 3W Standby |
| Certifications | |
| EMI / Safety | CE, FCC, LVD |
| Options | |
| Wall Mount Kit | VESA 75*75 mm |
| Base | Standard |
| MSR | Option |
| VFD | Option |
| 2nd Display | Option (8″~10.4″) |
